UL Certified ROHS PVC UL1284 Electrical Cable MTW 600V, 105℃ Bare Copper or Tinned Copper, 500kcmil with Black Color

Product Categories
ECHU Special Wire & Cable (Kunshan) Co., Ltd.
Contact Now

UL Certified ROHS PVC UL1284 Electrical Cable MTW 600V, 105℃ Bare Copper or Tinned Copper, 500kcmil with Black Color

Brand Name : ECHU

Model Number : UL1284

Certification : UL

Place of Origin : China

MOQ : 100meters

Price : USD0.313 to USD9.387/m

Supply Ability : 10000km per week

Packaging Details : in roll or splint reel

Payment Terms : T/T, Western Union

Color : Black/red/....

Voltage : 600V

Temperature : 105℃

Condutor : Bare copper or tinned copper

Contact Now

Product Description:

UL CERT.:E312831

UL1284: 1AWG, 2AWG, 3AWG,4AWG,5AWG,6AWG,7AWG,8AWG, 1/0AWG,2/0AWG, 3/0 AWG, 4/0AWG, 250Kcmil, 300kcmil,350kcmil, 400kcmil,450kcmil,500kcmil,500kcmil

Construction
Conductor :bare copper or tinned copper conductor Insulation: PVC
Standards
International: UL758 , UL1581
RoHS,REACH Compliant,
Technical data
Rated voltage:600V
Rated Temperature:105℃
Flame: VW-1, FT1, FT2
Oil resistance: 60 ℃ or 80 ℃ Oil
UL Certified ROHS PVC UL1284 Electrical Cable MTW 600V, 105℃ Bare Copper or Tinned Copper, 500kcmil with Black ColorUL Certified ROHS PVC UL1284 Electrical Cable MTW 600V, 105℃ Bare Copper or Tinned Copper, 500kcmil with Black Color
TYPE
Spec. AWG
Bare Copper
Tinned Copper
Insulation Thickness mm
Weight KG/KM
Conductor No.
Conductor Dia.
Conductor No.
Conductor Dia.
UL1284
8
118
0.3
118
0.30
2.03
138.4
UL1284
7
147
0.3
147
0.30
2.03
161.8
UL1284
6
189
0.3
189
0.30
2.03
194.9
UL1284
5
238
0.3
238
0.30
2.03
232.8
UL1284
4
299
0.3
299
0.30
2.03
279.0
UL1284
3
378
0.3
378
0.30
2.03
337.9
UL1284
2
475
0.3
475
0.30
2.03
409.1
UL1284
1
600
0.3
600
0.30
2.03
499.6
UL1284
1/0
251
0.52
272
0.50
2.03
609.7
UL1284
2/0
317
0.52
343
0.50
2.03
749.9
UL1284
3/0
400
0.52
433
0.50
2.03
924.3
UL1284
4/0
505
0.52
546
0.50
2.03
1142.9
UL1284
250
598
0.52
647
0.50
2.41
1372.4
UL1284
300
716
0.52
774
0.50
2.41
1617.7
UL1284
350
833
0.52
901
0.50
2.41
1859.5
UL1284
400
955
0.52
1033
0.50
2.41
2110.4
UL1284
450
1073
0.52
1161
0.50
2.41
2352.2
UL1284
500
1191
0.52
1288
0.50
2.41
2593.1
UL1284
550
1313
0.52
1420
0.50
2.79
2894.1
